基本細節:G122-829A P- I伺服放大器 用于閉環比例I/O?

G122-829A P- I伺服放大器用于閉環比例和/或積分放大器的應用是必要的。放大器內部的選擇開關使能
比例、積分或兩者皆可選擇。的許多方面放大器的特性可以通過內部選擇開關。這使得一個放大器可以用于許多不同的應用程序。提供的配置選項是多年設計經驗的結果嗎調試閉環系統。伺服放大器采用模擬電子學。它接受三個輸入信號，一個單端和兩個差分。這些被求和產生一個錯誤信號，然后按比例放大，也整合。的比例并將積分信號交換在一起，作為a輸出驅動伺服閥的電流或電壓。前面板裝飾盆，LED指示燈和測試點允許快速并且易于設置和幫助排除故障。伺服放大器的安裝在一個緊湊的DIN導軌安裝外殼和
需要+24V直流電源。
開關的選擇
?輸入1，延遲開啟或關閉
?反饋輸入4- 20ma或±10v
?輸入2,4 – 20ma或±10v
?比例控制，積分控制或兩者兼而有之
?從單位增益或放大誤差信號的積分器輸入
?積分器極限
?輸出±電流，±電壓或4-20 ma
?輸出電流電平

G122-829A P-

The G122-829A P-I servo amplifier is necessary for closed-loop proportional and/or integral amplifier applications. Selector switch inside amplifier enabled
You can choose a ratio, an integral, or both. Many aspects of the amplifier’s characteristics can be switched by internal selection. This allows one amplifier to be used for many different applications. The configuration options provided are the result of years of design experience debugging closed-loop systems. Servo amplifiers use analog electronics. It accepts three input signals, one single-ended and two differential. These are summed to produce an error signal, which is then scaled up and also integrated. The ratio and exchange the integral signal together as a output drives the current or voltage of the servo valve. Front panel decorated basins, LED indicators and test points allow for quick and easy setup and help troubleshoot. The servo amplifier is mounted in a compact DIN rail mount housing and
Requires +24V DC power supply.
Switch selection
? Enter 1 to delay opening or closing
? Feedback input 4-20ma or ±10v
? Input 2, 4-20mA or ±10v
? Proportional control, integral control or both
? Integrator input from unit-gain or amplified error signals
? Integrator limits
? Output ± current, ± voltage or 4-20 ma
? Output current level
