8C-PAINA1 集散控制系統 支持增強的熱管理

8C-PAINA1 C300控制器為集散控制系統(DCS)提供強大的魯棒控制?，F(xiàn)場驗證的確定性控制執行環境(CEE)的一個節點。核心軟件。CEE軟件提供了優越的控制執行和調度環境?？刂泼總€控制節點的策略都是通過一個通用的Control Builder配置和加載的直觀的工程工具。除了標準和健壯的預建功能塊和算法庫，C300控制器也支持自定義算法塊。自定義算法塊在目的和結構上與與Control Builder一起分發的標準功能塊。但是，cab具有用戶定義的算法以及數據結構，允許針對特定需求開發定制的策略。C300控制器與系列8 I/O共享其硬件設計，提供了一種創新的設計，減少了數據流占地面積、安裝和維護成本。C300控制模塊安裝在C300 Input上輸出終止組件(IOTA)。C300 IOTA僅包含F(xiàn)TE地址等無源設備開關。下面的圖1描述了IOTA組件。

8C-PAINA1特性
所有系列8組件都采用創新設計，支持增強的熱管理。這種獨特的外觀顯著減小等效函數的總體大小。系列8 I/O的獨特功能包括:
?I/O模塊和現場終端組合在同一區域。I/O模塊插入IOTA到消除了需要一個單獨的底盤來容納電子組件
?兩層“可拆卸”端子，用于將現場接線安裝在外殼中，使設備安裝更容易
和維護。
?通過IOTA提供現場電源，無需額外的電源為現場設備供電和相關的工藝有線編組
?冗余直接在IOTA上完成，無需任何外部電纜或冗余控制通過簡單地向IOTA添加第二個IOM來實現
?對于IOM和IOTA，涂層(模塊編號以8C開頭)和未涂層(模塊編號以8C開頭)提供8U)選項。保形涂層材料應用于電子電路起到保護作用防止?jié)駳狻⒒覊m、化學物質和極端溫度。建議使用涂層IOM和IOTA當電子產品必須承受惡劣的環境和額外的保護是必要的。

8C-PAINA1

The 8C-PAINA1 C300 controller provides robust control for distributed control systems (DCS). Field-verified deterministic control execution environment (CEE) for a node. The core software. CEE software provides a superior control execution and scheduling environment. The policies that Control each control node are intuitive engineering tools configured and loaded through a common Control Builder. In addition to standard and robust pre-built function blocks and algorithm libraries, the C300 controller also supports Custom algorithm blocks (cab). A custom algorithm block is a standard function block distributed with Control Builder in purpose and structure. However, cab has user-defined algorithms as well as data structures that allow customized policies to be developed for specific needs. The C300 controller shares its hardware design with the Series 8 I/O, providing an innovative design that reduces data flow footprint, installation and maintenance costs. The C300 control module is installed on the C300 Input Output Termination Component (IOTA). C300 IOTA contains only passive device switches such as FTE addresses. Figure 1 below depicts the IOTA components.

8C-PAINA1 characteristics
All Series 8 components are innovatively designed to support enhanced thermal management. This unique appearance significantly reduces the overall size of the equivalent function. Unique features of Series 8 I/O include:
?I/O modules and field terminals are combined in the same area. I/O modules are inserted into IOTA to eliminate the need for a separate chassis to house the electronic components
? Two layers of “detachable” terminals for mounting field wiring into the housing, making device installation easier
And maintenance.
? Provide field power via IOTA, eliminating the need for additional power to power field equipment and associated process wiring
Redundancy is done directly on IOTA without any external cables or redundant controls by simply adding a second IOM to IOTA
? For IOM and IOTA, options are available for coated (module number starts with 8C) and uncoated (module number starts with 8C). Conformal coating materials are used in electronic circuits to protect against moisture, dust, chemicals and extreme temperatures. IOM and IOTA coatings are recommended when electronic products must withstand harsh environments and additional protection is necessary.
