基本細節:PLATE?F860-CA 現場總線接口模塊 兩個冗余配置

PLATE F860-CA設計用于與霍尼韋爾Experion“系列C”現場總線接口模塊一起使用時，為八個基金會現場總線”“H1段提供冗余電源。模塊支架符合11.6英寸I/O終端組件的機械和電氣要求，可直接安裝到霍尼韋爾安裝通道中。現場總線段的電源由兩個冗余配置的電源模塊f801或f802提供。故障報警，電流隔離，電源調節和段終止被納入每個F80x模塊。在單工應用中，可以使用單個F80x模塊。當安裝單個或幾余F80x模塊時，自動維護現場總線段的終止，為了保證極高的可靠性，F(xiàn)860 IOTA采用無源模式，僅提供電源模塊與外部連接的互連。IOTA有兩個多針連接器，每個連接器都通過標準系統電纜連接到FIM IOTA。
不同的長度可供選擇，以適應F860及其各自的FIM iota在系列C IO機柜內的不同位置的安裝?，F(xiàn)場接線連接在FIM IOTA.·8個現場總線段的冗余電源
·8段冗余“系列C”I/O兼容
高密度，緊湊的設計
.11.6英寸IOTA格式
·最高級別的可用性
·完全隔離
·低功耗
·遠程報警設施
·在線診斷選項
·F801輸出21.5V 350mA
·F802輸出28V 500mA

PLATE?F860-CA

The PLATE F860-CA is designed to provide redundant power to eight Foundation fieldbuses H1 segments when used with the Honeywell Experion “Series C” Fieldbus Interface Module (fim). The module bracket meets the mechanical and electrical requirements of the 11.6-inch I/O Terminal Assembly (iota) and can be installed directly into the Honeywell installation channel. The fieldbus segment is powered by two redundant power modules f801 or f802. Fault warning, current isolation, power regulation and segment termination are incorporated into each F80x module. In simplex applications, a single F80x module can be used. When one or more F80x modules are installed, the F860 IOTA automatically maintains the termination of the fieldbus segment. To ensure high reliability, the F860 IOTA adopts passive mode and only provides the interconnection between the power module and external connections. IOTA has two multi-pin connectors, each connected to FIM IOTA via a standard system cable.
Different lengths are available to accommodate the installation of the F860 and its respective FIM iota in different locations within the Series C IO cabinet. Field wiring is connected to the redundant power supply in FIM IOTA.·8 fieldbus segments
· 8-stage redundant “Series C” I/O compatibility
High density, compact design
11.6-inch IOTA format
· Highest level of usability
· Complete isolation
· Low power consumption
· Remote alarm facilities
· Online diagnostic options
·F801 output 21.5V 350mA
·F802 output 28V 500mA

如果您需要查詢或購買，請將產品型號發送到我的電子郵件或直接致電我

銷售經理:何經理

手機: + 86 18005021035

郵箱:?18005021035@163.com

與成都陽光熹禾合作我們提供一流的服務，實現更快的速度，交付多樣化的零件!

1.在24小時內及時回復您

2.交貨時間快

3.最好的服務，合理的價格

4.在生產線上工作多年，有良好的口碑

▲更多相關型號: PLATE?F860-CA 現場總線接口模塊 兩個冗余配置
