基本細節:PCI-6230 8路AI 直流耦合和250 KS/s的最大采樣率

8路AI，（16位，250 kS/s），4路DIO，組隔離，5 V TTL/CMOS PCI多功能I/O設備—PCI-6230提供了模擬輸入、數字輸出、兩個32位計數器/定時器和組隔離。隨附的NI-DAQmx驅動程序和配置實用程序簡化了配置和測量。
sPCI-6230（部件號：779615-01、192236A-01）是M系列的組隔離式多功能數據采集板。該器件將隔離的性能和安全優勢與精確控制和測量所需的高性能放大、定時和校準技術完美結合。NI PCI-6230 內置 的 組 隔離 功能 可 提供 噪聲 抑制、瞬態 安全 、 減少 接地 環路 以及 共模 電壓 抑制。
該器件是高電壓和高電噪聲環境中應用的理想解決方案。NI PCI 6230 DAQ 可 與 接近 傳感器、 控制 閥 、 泵 、 流量 計 、 繼電器 等 一起 使用 。該DAQ板具有8個單端或4個差分模擬輸入，通過16位分辨率ADC，具有±10 V、±5 V和±1 V、±0.2 V輸入范圍、直流耦合和250 KS/s的最大采樣率，時序精度為50 ppm。NI PCI 6230 具有高達 60 VDC 的連續組隔離和高達 1950 VDC 的通道到總線隔離。
該型號設計有四個模擬輸出通道，由 16 位數模轉換器提供支持。每個模擬輸出通道可實現的最大更新速率為 500 kS/s。用戶可以達到每通道 450、425 和 400 KS/s 的更新速率，同時分別使用兩個、三個或四個通道。NI PCI-6230 支持 直流 輸出 耦合， 輸出 范圍 為 ± 10 V。該器件內置的輸出 FIFO 可以處理 8,191 個，并在通道之間共享。對于邊沿、半周期、周期和其他計數器測量，PCI-6230具有兩個32位計數器/定時器，工作頻率為80 MHz。該器件配備 37 引腳 D-SUB I/O 連接器。
PCI-6230使用NIDAQmx驅動程序軟件運行，該軟件可以使用軟件包或應用程序開發環境（ADE）進行編程，如LabVIEW或LabWindows/CVI。NI 設備 重 0.24 磅，尺寸為 3.8 x 6.1 英寸。在物理維度上。它的推薦工作溫度范圍為 0 至 55 °C.

PCI-6230

8-way AI, (16-bit, 250 kS/s), 4-way DIO, Group isolation, 5 V TTL/CMOS PCI Multi-function I/O device – The PCI-6230 provides analog input, digital output, two 32-bit counters/timers, and group isolation. The included NI-DAQmx driver and configuration utility simplify configuration and measurement.
The sPCI-6230 (Part number: 779615-01, 192236A-01) is a group isolated multi-function data acquisition board for the M series. The device combines the performance and safety benefits of isolation with the high-performance amplification, timing and calibration technologies needed for precise control and measurement. The NI PCI-6230’s built-in group isolation provides noise suppression, transient safety, reduced ground loops, and common mode voltage suppression.
The device is an ideal solution for applications in high voltage and high electrical noise environments. The NI PCI 6230 DAQ can be used with proximity sensors, control valves, pumps, flow meters, relays, and more. The DAQ board features eight single-ended or four differential analog inputs with ±10 V, ±5 V and ±1 V, ±0.2 V input range, DC coupling, and a maximum sampling rate of 250 KS/s with 50 ppm timing accuracy via a 16-bit resolution ADC. The NI PCI 6230 features continuous-group isolation up to 60 VDC and channel to bus isolation up to 1950 VDC.
The model is designed with four analog output channels supported by a 16-bit digital-to-analog converter. Each analog output channel can achieve a maximum update rate of 500 kS/s. Users can achieve update rates of 450, 425 and 400 KS/s per channel while using two, three or four channels, respectively. The NI PCI-6230 supports DC output coupling with an output range of ± 10 V. The device’s built-in output FIFO can handle 8,191 and is shared between channels. For edge, half-period, period, and other counter measurements, the PCI-6230 has two 32-bit counters/timers operating at 80 MHz. The device is equipped with a 37-pin D-SUB I/O connector.
PCI-6230 runs with NIDAQmx driver software, which can be programmed using a software package or application development environment (ADE) such as LabVIEW or LabWindows/CVI. The NI device weighs 0.24 pounds and measures 3.8 x 6.1 inches. In the physical dimension. Its recommended operating temperature range is 0 to 55 °C.
