The following I/O modules can be used to create customizations
Control solutions.
? 16-channel universal IO module Galaxy isolated input/output to chassis (p.29)
? 8-point universal analog input modules: electrically isolated point-to-case inputs can be mixed on the module and may include multiple thermocouple types, rtd, ohm, voltage, or grinding voltage types – all of which can be easily assigned using the process Control Designer configuration tool. High point to point electrical isolation simplifies installation and saves on the cost of external isolation hardware (page 8).
? 16-point high level analog input module: Each point can be configured as V or mA. Electrical isolation point to chassis. Point-to-point electrical isolation (page 12). 250 ohms of shunt resistance can be added per channel.
? 4-point electrical isolation analog output module. Electrical isolation points to chassis supports, each from 0 to 20ma
Slow data: Since the speed of the 1/0 device is low and the CPU and memory speed is high, a buffer must be set in the controller. At output, the buffer is used to temporarily store the data coming from the host at high speed, and then the data in the buffer is transmitted to the |/0 device at the rate that the I/0 device has. On input, the buffer is used to temporarily store the slave! The data sent by the /0 device, after receiving a batch of data, the data in the buffer is transmitted to the host at high speed.
Error control: The device controller is also responsible for error detection of the data transmitted by the I/O device. If an error is found in the transmission, the error detection code is usually set and reported to the CPU, so the CPU will cancel the data sent this time and retry the transmission. This ensures the correctness of data input. Data exchange: This refers to the realization of data exchange between the CPU and the controller, and between the controller and the device. For the former, through the data bus, the CPU writes the data to the controller in parallel, or reads the data from the controller in parallel; In the latter case, the device inputs data to the controller, or from the controller to the device. For this purpose, a data register must be set up in the controller. Status description: Identifying and reporting the status of the device The controller records the status of the device for the CPU to understand. For example, the CPU can start the controller to read data from the device only when the device is in the send-ready state. To this end, a status register should be set up in the controller, and each bit of it reflects a certain state of the device. When the CPU reads the content of the memory, it can understand the state of the device.
