Alen-Bradley 1753-L32BBBM-8A是GuardPLC 1800系列的安全控制器。該控制器是GuardPLC控制器中/0點數最多的控制器。它配有32個I/0點(24個輸入和8個輸出，沒有一個是電氣隔離的)。輸出通道4和8可以承受60攝氏度時1安培的電流，其他通首的額定電流為0.5安培。1753-L32BBBM-8A控制器還有2個24位分率的高速計數器(手電氣隔離。安裝了250 KB的用戶程存儲器和250 KB的應用數據存儲器，以支持微處理器進行故障處理。該設備將檢測其控制系統行為中的故障，并將來自故障模塊的所有受影響的輸入和輸出置于安全狀態
1753-L32BBBM-8A uardPLC 1800控制器的特殊功能是Modbus通信選項。通過使用該通信協議，用戶可以與其他工業自動化設備交換信號值和其他數據。要對安全控制器如何對故障條件做出反應進行編程，用戶必須獲得“RSLogix Guard PLUS!”編程軟件。Allen-Bradley 1753-L32BBBM-8A設計用于連接24伏DC/8安培電源。它裝在IP20防護外殼中，尺寸為114毫米(4.49英寸)x 257毫米(10.1英寸)x 80毫米(3.15英寸)，包括屏蔽板。它的重量約為2.6磅(1.2公斤)。請勿在0至60攝氏度(32至140華氏度)的溫度范圍之外使用本設備?？刂破魍ㄟ^了嚴格的測試，通過了CE、C-Tick和C-UL-美國標準的認證。

1753-L32BBBM-8A

Allen-Bradley 1753-L32BBBM-8A控制器是一種工業控制器，是Allen-Bradley GuardPLC系列的一部分，旨在用作完整GuardPLC系統的一部分。它配有24路非電氣隔離的數字輸入和8路非電氣隔離的數字輸出。1753-L32BBBM-8A控制器也有8個單極性、非電氣隔離的模擬輸入。該控制器的工作溫度范圍為32至140華氏度，存儲溫度范圍為-40至185華氏度。1753-L32BBBM-8A控制器的防護等級相對較低，為IP 20。

1753-L32BBBM-8A

The Alen-Bradley 1753-L32BBM-8A is a safety controller for the GuardPLC 1800 series. This controller has the highest number of /0 points among GuardPLC controllers. It has 32 I/0 points (24 inputs and 8 outputs, none of which are electrically isolated). Output channels 4 and 8 can withstand currents of 1 amp at 60 degrees Celsius, and the other through-heads are rated at 0.5 amp. The 1753-L32BBM-8A controller also has two 24-bit fractional rate high-speed counters (hand electrical isolation. 250 KB of user program memory and 250 KB of application data memory were installed to support the microprocessor for troubleshooting. The device will detect faults in the behavior of its control system and place all affected inputs and outputs from the failed module in a safe state
A special feature of the 1753-L32BBM-8A uardPLC 1800 controller is the Modbus communication option. By using this communication protocol, users can exchange signal values and other data with other industrial automation equipment. To program how the security controller reacts to failure conditions, users must obtain the “RSLogix Guard PLUS!” Programming software. The Allen-Bradley 1753-L32BBM-8A is designed to connect to a 24 volt DC/8 amp power supply. It is housed in an IP20 protective housing and measures 114 mm (4.49 in)x 257 mm (10.1 in)x 80 mm (3.15 in), including the shield plate. It weighs about 2.6 pounds (1.2 kg). Do not use this device outside the temperature range of 0 to 60 degrees Celsius (32 to 140 degrees Fahrenheit). The controller has passed rigorous testing and is certified to CE, C-Tick and C-UL-USA standards.

The Allen-Bradley 1753-L32BBM-8A controller is an industrial controller that is part of the Allen-Bradley GuardPLC family and is intended to be used as part of a complete GuardPLC system. It has 24 non-electrically isolated digital inputs and 8 non-electrically isolated digital outputs. The 1753-L32BBM-8A controller also has eight unipolar, non-electrically isolated analog inputs. The controller has an operating temperature range of 32 to 140 degrees Fahrenheit and storage temperature range of -40 to 185 degrees Fahrenheit. The 1753-L32BBM-8A controller has a relatively low protection rating of IP 20.
