1797- PS2E2模塊是由Allen- Bradley設計和制造的FLEX EX /0系列本質安全I(xiàn)ECEX 24伏DC額定電源模塊。1797-PS2E2 PSU(電源裝置是本質安全

系統最重要的組件之一。其期的是將輸入 電源電路與相關電氣控制電路的危險區域隔離，并禁止電路問題從輸入側轉移到輸出側。1797-PS2E2模塊

的另-項任務是設置可用能量的限值，并將其調整至規定的安全水平。所有4個輸出通道可以獨立地被限制。1797-PS2E2安全I(xiàn)ECEX PSU模塊為其4

個輸出通道中的每個通道提供8.5瓦的功率。這種用于爆炸性環境的特殊裝置輸出的額定電壓為24伏DC,這是在危險區域連接到FLEX Ex系統的組件

所需的唯一電源。 24伏DC電壓的輸入接頭位于接線端1、2、4和5。 有4個端子覆蓋2個電源輸入，用于電源輸入冗余?？山邮艿妮斎腚妷悍秶?8

到32伏DC。

1797-PS2E2

Allen-Bradley 1797- PS2E24-Ex輸出DC電源模塊采用IP 65/NEMA 7B級防火外殼，該外殼改進了輸入和輸出的安全終端。輸入DC電源壓蓋是一個

M20x1 5,可以接受直徑為6至12毫米的電纜。功率輸出壓蓋(共有4個)為M16x1 5,可接受4至8毫米寬的電纜。通過這些電纜，電力傳輸?shù)綀?zhí)行

器、閥門、傳感器或變送器。1797- PS2E2模塊支持帶電拆卸和插入,這使得系統運行時能夠在危險區域進行電纜連接。

1797-PS2E2

The 1797-PS2E2 module is a FLEX EX /0 series intrinsically safe IECEX 24 volt DC rated power module designed and manufactured by Allen-Bradley. 1797-PS2E2 PSU(Power supply unit is intrinsically safe

One of the most important components of the system. The goal is to isolate the input power circuit from the hazardous area of the associated electrical control circuit, and to prohibit the transfer of circuit problems from the input side to the output side. 1797-PS2E2 module

The other task is to set the limit of available energy and adjust it to the specified safe level. All 4 output channels can be restricted independently. 1797-PS2E2 The IECEX PSU module is its 4

Each of the output channels provides 8.5 watts of power. This special unit for explosive environments outputs a rated voltage of 24 volts DC, which is the component connected to the FLEX Ex system in hazardous areas

The only power source needed. Input connectors for 24 volts DC are located at terminals 1, 2, 4 and 5. There are 4 terminals covering 2 power inputs for power input redundancy. The acceptable input voltage range is 18

To 32 volts DC.

The Allen-Bradley 1797-PS2E24-Ex Output DC power module features an IP 65/NEMA Class 7B fireproof housing with improved input and output security terminals. Input DC power supply gland is one

The M20x1 5 can accept cables with diameters from 6 to 12 mm. The power output gland (of which there are four) is M16X5 and accepts cables 4 to 8 mm wide. Through these cables, power is transmitted to the execution

Device, valve, sensor or transmitter. The 1797-PS2E2 module supports live disassembly and insertion, which enables cable connections in hazardous areas while the system is in operation.
