Triconex 3721產品系列包括一系列模塊。本節包括：系統組件及其用途的摘要，列出標準產品及其型號的表格，以及Tricon系列中每個標準產品的規格摘要。有關完整信息，請參閱《Tricon規劃和安裝指南》。

Triconex 3721機箱

?主機箱容納主處理器、內存?zhèn)溆秒姵?、通信模塊和I/O模塊。

?擴展機箱，用于距離主機箱不超過100英尺（30米）的其他I/O模塊。在受限應用中，支持高達1000英尺（300米）的操作。

?適用于距離主機箱不超過7.5英里（12公里）的I/O模塊的RXM機箱。

?機械鍵控Tricon中的每個插槽都通過機械鍵控與特定類型的模塊相對應。這樣可以防止將模塊安裝到不合適的插槽中。

光纖遠程擴展模塊（RXM）

用于距離主機箱7.5英里（12公里）的擴展機箱的操作，具有對靜電和電磁干擾的特殊免疫力。

Triconex 3721 I/O模塊?數字輸入模塊

接收這些標稱電壓的離散信號：115 VAC/VDC、48 VAC/VDC和24 VAC/VDC。TMR模塊中提供所有電壓。非TMR模塊僅提供24 VDC和48 VDC電壓。還提供速度輸入和累計模塊。

?監控?cái)?shù)字輸出模塊產生這些標稱電壓的離散輸出信號，現場電路和負載設備的診斷范圍：115 VAC、120 VDC、48 VDC和24 VDC。

?數字輸出模塊產生這些標稱電壓的離散輸出信號：115 VAC、120 VDC、24和48 VDC。還提供雙輸出模塊。

?模擬輸入模塊接收以下類型的模擬信號：0-5 VDC、-5至+5 VDC、0-10 VDC和J、K、T和E型熱電偶。有隔離和DCcoupled兩種版本。

?模擬輸出模塊驅動八個4-20 mA模擬輸出信號。大電流AO模塊包括4-20 mA的6個點和20-320 mA的2個點。

3721

控制脈沖輸入：TRICONEX 3721模塊支持控制脈沖信號的輸入，可以接收外部設備發送的脈沖信號，用于觸發或控制相關操作。它具備高精度和穩定性，可滿足精密控制需求。

控制脈沖輸出：該模塊還提供控制脈沖信號的輸出功能，可通過輸出端口發送脈沖信號給其他設備或系統。這些輸出信號可用于同步操作、定時控制或其他需要脈沖觸發的應用。

多通道支持：TRICONEX 3721模塊通常提供多個獨立的通道，每個通道都可以單獨配置和控制。這使得它能夠同時處理多個不同的控制脈沖輸入和輸出任務，增加了系統的靈活性和擴展性。

靈活配置和管理：該模塊具備靈活的配置和管理功能。用戶可以通過配置工具和接口對模塊進行參數設置和監控，包括脈沖頻率、脈沖寬度、脈沖觸發條件等。這樣可以根據實際需求進行定制化配置和管理。

可靠性和耐用性：霍尼韋爾作為工業自動化領域的知名品牌，其模塊具有高可靠性和耐用性。TRICONEX 3721模塊經過嚴格的質量控制和測試，能夠在惡劣的工業環境中穩定運行，并具備長時間的使用壽命。

3721

The Triconex 3721 product family includes a range of modules. This section includes: a summary of system components and their uses, a table listing standard products and their models, and a specification summary for each standard product in the Tricon family. For complete information, see the Tricon Planning and Installation Guide.

Triconex 3721 chassis

? The main box houses the main processor, memory backup battery, communication module, and I/O module.

Expansion chassis for other I/O modules not more than 100 feet (30 meters) from the main chassis. In restricted applications, operations up to 1,000 feet (300 m) are supported.

RXM chassis for I/O modules not more than 7.5 miles (12 km) from the main chassis.

? Mechanical Keying Each slot in Tricon is mechanically keyed to a specific type of module. This prevents the module from being installed in an inappropriate slot.

Optical Fiber Remote Expansion Module (RXM)

For operation of the extension chassis at a distance of 7.5 miles (12 km) from the main chassis, with special immunity to electrostatic and electromagnetic interference.

Triconex 3721 I/O Module ? Digital input module

Receive discrete signals at these nominal voltages: 115 VAC/VDC, 48 VAC/VDC, and 24 VAC/VDC. All voltages are available in the TMR module. Non-tmr modules offer only 24 VDC and 48 VDC voltages. Speed input and accumulation modules are also available.

Monitor digital output modules that produce discrete output signals at these nominal voltages, with diagnostic ranges for field circuits and load devices: 115 VAC, 120 VDC, 48 VDC, and 24 VDC.

Digital output modules generate discrete output signals at these nominal voltages: 115 VAC, 120 VDC, 24 and 48 VDC. Dual output modules are also available.

? Analog input modules receive the following types of analog signals: 0-5 VDC, -5 to +5 VDC, 0-10 VDC, and type J, K, T, and E thermocouples. There are isolated and DCcoupled versions.

? The analog output module drives eight 4-20 mA analog output signals. The high-current AO module consists of 6 points from 4-20 mA and 2 points from 20-320 mA.

Control pulse input: The TRICONEX 3721 module supports the input of control pulse signals and can receive pulse signals sent by external devices for triggering or controlling related operations. It has high precision and stability to meet the needs of precise control.

Control pulse output: The module also provides the output function of control pulse signal, which can send pulse signal to other devices or systems through the output port. These output signals can be used for synchronous operation, timing control, or other applications that require pulse triggering.

Multi-channel support: The TRICONEX 3721 module typically provides multiple independent channels, each of which can be configured and controlled individually. This enables it to handle multiple different control pulse input and output tasks simultaneously, increasing the flexibility and scalability of the system.

Flexible configuration and management: The module has flexible configuration and management functions. The user can set and monitor the parameters of the module through the configuration tool and interface, including pulse frequency, pulse width, pulse triggering conditions, etc. In this way, you can customize the configuration and management based on actual requirements.

Reliability and durability: Honeywell is a well-known brand in the field of industrial automation, and its modules are highly reliable and durable. The TRICONEX 3721 module has undergone rigorous quality control and testing to ensure stable operation in harsh industrial environments and a long service life.

3721
