5136-dnp-pci 選用不銹鋼原料，外殼選用鑄鋁工業性防爆外殼，具有很強的抗腐蝕性和長時間穩定性及抗干擾才能。傳感器在寬溫度范圍內進行了溫度補償，保證了傳感器的技術指標。可配接led、lcd、指針、百分表等顯示表頭，有多種壓力接口螺紋形式，能極限的滿意客戶需要。廣泛應用于氣/液壓力測控體系、工業進程控制、石油、化工、冶金、恒壓供水等范疇。

可選用hart協議板或rs485板。可選配我公司研制出產的各種測控儀表或電路模塊。

5136-DNP-PCI

技術指標

量 程：-0.1~100~200mpa；

精 度：0.1% fs、0.25% fs、0.5% fs、1.0 % fs 可選；

供電電壓：傳感器：+5~12vdc； 變送器：+24vdc、、+12vdc、、+5vdc、；

輸出信號：傳感器：1mv/v；變送器：0/0.5/1.0~4.0/4.5/5.0/10.0v (三線制)，4~20ma(兩/三線制)；

負載才能（變送器）：電流型 ≤500r； 電壓型 ≥100kr；

零點差錯：?0.5% fs；

滿度差錯：?1.0% fs；

補償溫度： -10℃~70℃；

工作環境： -20℃~75℃；

工作環境： -20℃~75℃，≤85%rh；

儲存環境： -40℃~85℃，≤95%rh；

安全過載才能：150%；

極限過載才能：250%；

溫度漂移： 0.03%fs/℃；

長時間穩定性：0.2%fs/年；

外殼材料： 316不銹鋼；

5136-DNP-PCI

5136-dnp-pci selection of stainless steel raw materials, the shell selection of cast aluminum industrial explosion-proof shell, with strong corrosion resistance and long-term stability and anti-interference ability. The sensor has temperature compensation in a wide temperature range to ensure the technical index of the sensor. Can be matched with led, lcd, pointer, dial indicator and other display head, there are a variety of pressure interface thread forms, can limit the satisfaction of customer needs. Widely used in gas/liquid pressure measurement and control system, industrial process control, petroleum, chemical industry, metallurgy, constant pressure water supply and other fields.

hart protocol board or rs485 board can be used. Various measurement and control instruments or circuit modules developed and produced by our company can be selected.

2. Technical indicators

Measuring range: -0.1~100~200mpa;

Precision: 0.1%fs, 0.25%fs, 0.5%fs, 1.0%fs optional;

Supply voltage: Sensor: +5~12vdc; Transmitter: +24vdc, +12vdc, +5vdc,

Output signal: Sensor: 1mv/v; Transmitter: 1.0/0/0.5 ~ 4.0/4.5/5.0/10.0 v (three-wire system), 4 ~ 20 ma (two/three wire system);

Load capacity (transmitter) : current type ≤500r; Voltage type ≥100kr;

Zero error:? 0.5% fs;

Full degree error:? 1.0% fs;

Compensation temperature: -10℃~70℃;

Working environment: -20℃~75℃;

Working environment: -20℃~75℃, ≤85%rh;

Storage environment: -40℃~85℃, ≤95%rh;

Safety overload ability: 150%;

Limit overload capacity: 250%;

Temperature drift: 0.03%fs/℃;

Long-term stability: 0.2%fs/ year;

Housing material: 316 stainless steel;

5136-DNP-PCI
