ABB CI858K01 3BSE018135R1 DriveBus 接口，CI858K01 DriveBus 接口套件包包括: CI858,通信接口。TP858,底板，寬度 = 60毫米，交號EXC3BSE018135R1。
型號: CI858K01
產品編號: 3BSE018135R1
DriveBus 協議用于與 ABB Drives 和 ABB Special /0 單元進行通信，DriveBus 通過 CI858 通信接口單元連接到控制器。DriveBus 接口用于 ABBDrives 和 AC 800M 控制器之間的通信。
DriveBus 通信專為 ABB 機區動系統 ABB 造紙機控制系統的分段動應用而設計。C1858 由處理器單元通過 CEX 總線供電，因此不需要任何額外的外部電源。
特點和好處
。 DriveBus 支持熱插拔
。一C1858 最多可以連接 24 ABB 驅動器，一個 AC 800M 控制器最多可以連接兩 CI858如果多 ABB 驅動器連接到 CI858，則需要個分支單元 NDBU，它可以構建具有物理星形拓?fù)涞倪壿嬁偩€。分支單元可以被鏈接.包裝包括:
– CI858，通信接口
-TP858，底板

CI858K01

ABB發明、制造了眾多產品和技術，其中包括全球第一套三相輸電系統、世界上第一臺自冷式變壓器、高壓直流輸電技術和第一臺電動工業機器人，并率先將它們投入商業應用。ABB擁有廣泛的產品線，包括全系列電力變壓器和配電變壓器，高、中、低壓開關柜產品，交流和直流輸配電系統，電力自動化系統，各種測量設備和傳感器，實時控制和優化系統，機器人軟硬件和仿真系統，高效節能的電機和傳動系統，電力質量、轉換和同步系統，保護電力系統安全的熔斷和開關設備。這些產品已廣泛應用于工業、商業、電力和公共事業中。

ABB集團位列全球500強企業（2008年在世界500強排列第256位，2009年位列第230位，2010年位列第237位），2009至2011年銷售額都高達320億美元。并在蘇黎世、斯德哥爾摩和紐約證券交易所上市交易。

安全回路是保護負載或控制對象以及防止操作錯誤或控制失敗而進行連鎖控制的回路。在直接控制負載的同時，安全保護回路還給PLC輸入信號，以便于PLC進行保護處理。安全回路一般考慮以下幾個方面。

CI858K01

ABB CI858K01 3BSE018135R1 DriveBus interface, CI858K01 DriveBus interface package includes: CI858, communication interface. TP858, base plate, width = 60 mm, intersection number EXC3BSE018135R1.
Model: CI858K01
Product Number: 3BSE018135R1
The DriveBus protocol is used to communicate with ABB Drives and ABB Special /0 units, and DriveBus is connected to the controller via the CI858 communication interface unit. The DriveBus interface is used for communication between ABBDrives and the AC 800M controller.
DriveBus communication is specially designed for the segmented dynamic applications of ABB’s paper machine control systems. The C1858 is powered by the processor unit via the CEX bus, so no additional external power is required.
Features and benefits
. DriveBus supports hot swapping
. One C1858 can connect up to 24 ABB drives, one AC 800M controller can connect up to two CI858 If multiple ABB drives are connected to the CI858, a branch unit NDBU is required, which can build a logical bus with a physical star topology. Branch units can be linked. The package includes:
– CI858, communication port
-TP858, mainboard
ABB invented and manufactured many products and technologies, including the world’s first three-phase power transmission system, the world’s first self-cooling transformer, high-voltage direct current transmission technology and the first electric industrial robot, and pioneered their commercial application. ABB has a wide range of product lines, including a full range of power transformers and distribution transformers, high, medium and low voltage switchgear products, AC and DC transmission and distribution systems, power automation systems, various measuring equipment and sensors, real-time control and optimization systems, robotics hardware and software and simulation systems, energy-efficient motors and drive systems, power quality, conversion and synchronization systems, and other systems. Fusing and switching equipment to protect the safety of power systems. These products have been widely used in industry, commerce, power and public utilities.

ABB is one of the world’s top 500 companies (256th in 2008, 230th in 2009, 237th in 2010), with sales of $32 billion in 2009-2011. It is listed on the Zurich, Stockholm and New York Stock exchanges.

A safety loop is a loop of interlocking control that protects the load or control object and prevents operational errors or control failures. In the direct control of the load at the same time, the safety protection loop to the PLC input signal, in order to facilitate the PLC protection processing. Safety circuits generally consider the following aspects.

CI858K01
