CI871A是通過以太網連接到PROFINET 0設備的AC 800M通信接口。TP867 Baseplate有兩RJ45以太網連接器，但只有支持100Mbps的CH1連接器用于PROFINETIO連接。以太網電纜必須通過以太網交換機連接到PROFINET O網絡。CI871擴展單元包含CEX總線邏輯、通信單元和DC/DC轉換器，用于通過CEX總線提供所需電壓+24 V。CI871A模塊僅適用于System 800xA 6.0.3.3、6.1.1和更高版本
CI871A是一個AC 800M通信接口，通過以太網與PROFINET 0設備連接TP867 Baseplate有兩RJ45以太網連接器，PROFINET I0連接只使用支持100Mbps的CH1連接器。以太網線纜必須通過以太網交換機連接到PROFINET O網絡C1871擴展單元包含CEX-Bus邏輯、通信單元和DC/DC轉換器，該轉換器從+ 24v電源通過CEX-Bus提供所需電壓.CI871A模塊只適用于Svstem 800xA 6.0.3.3、6.1.1和后續版本

CI871K01

特點和優點
通過以太網連接PROFINETIO設備
介質描述:封裝包括: – CI871，通信接口- TP867，底板產品類型: Communication Module訂購海關編碼: 851762-電話機，包括用于蜂窩網絡或其他無線網絡的電話:用于傳輸或接收語音、圖像或其他數據的其他設備，包括在有線或無線網絡(諸如局域網或廣域網)中進行通信的設備，但標題為84.43、85.25、85.27或85.28的傳輸或接收設備除外。包括在有線或無線網絡(如局域網或廣域網)中進行通信的設備:-用于接收、轉換和傳輸或再生語音、圖像或其他數據的機器，包括交換和路由設備海關關稅號: 8517620000尺寸產品凈深度/長度:127.5 毫米產品凈高:185 毫米產品凈重:59 毫米產品凈重: 0.65 千克環境的ROHS 狀態:遵循歐盟指令 2011/65/EU報廢電子電氣設備類別: 5,小型設備(部尺寸不超過50厘米) 電池數量: 0

CI871K01

The CI871A is an AC 800M communication interface connected to the PROFINET 0 device over Ethernet. The TP867 Baseplate has two RJ45 Ethernet connectors, but only the 100Mbps CH1 connector is used for PROFINETIO connectivity. The Ethernet cable must be connected to the PROFINET O network through an Ethernet switch. The CI871 expansion unit contains the CEX bus logic, communication unit, and DC/DC converter to provide the required voltage +24 V over the CEX bus. The CI871A module is only available for System 800xA 6.0.3.3, 6.1.1 and later
The CI871A is an AC 800M communication interface that connects to the PROFINET 0 device over Ethernet. The TP867 Baseplate has two RJ45 Ethernet connectors, and the PROFINET I0 connection uses only the CH1 connector that supports 100Mbps. Ethernet cables must be connected to the PROFINET O network via an Ethernet switch. The C1871 expansion unit contains the CEX-Bus logic, communication unit, and DC/DC converter that provides the required voltage from a + 24v power supply via the CEX-Bus. The CI871A module is only available for Svstem 800xA 6.0.3.3, 6.1.1 and later versions
Features and advantages
Connect PROFINETIO devices over Ethernet
Media description: Package includes: -CI871, Communication interface -TP867, baseboard Product type: Communication Module Order Customs Code: 851762- Telephone sets, including telephones for cellular or other wireless networks: other devices used to transmit or receive voice, images, or other data, including devices for communication in wired or wireless networks such as local or wide area networks, Except for transmission or receiving devices with headings 84.43, 85.25, 85.27 or 85.28. Includes equipment that communicates in wired or wireless networks (such as local or wide area networks) :- Machines used to receive, convert and transmit or regenerate voice, images or other data, including switching and routing equipment 8517620000 Size Product Net depth/Length :127.5 mm Product net height :185 mm Product Net weight :59 mm product net weight: 0.65 kg Environmental ROHS status: Compliance with EU Directive 2011/65/EU Waste electrical and electronic equipment Category: 5, small equipment (part size does not exceed 50 cm) Number of batteries: 0

CI871K01
