HydranTM 201Ti是一款小型且易于設置的連續油中溶解氣體分析(DGA)監測儀。
它提供了IEEE?標準C57.104所使用的基本信息，可以作為必不可少的第一個
為你的艦隊中的變形金剛提供防線以獲得故障情況的提前警告
將計劃外中斷的風險降至最低。
201Ti的復合氣體傳感器使用燃料電池提供世界知名的“Hydran氣體值”
技術(描述為固定儀器。標準中方法3)。它對氫的反應是100%
(一般故障氣體)，也對一氧化碳(紙張過熱)，乙炔(電弧)和
乙烯(油過熱)，從而涵蓋了變壓器所有主要故障的根本原因。
由于監測單元安裝在單個閥門上，并使用動態油采樣，因此沒有
需要一個泵或額外的管道連接到不同的閥門。由于其簡單的特點和
它提供了易于理解的信息，201Ti已成為首選的監視器之一
多年來，擁有任何監視器中最大的安裝基礎之一。
與最新的Mark IV版本，Hydran 201Ti顯示器已經完全大修與新的
電子電路板和電源使其符合RoHS標準，解決任何過時的問題和
進一步改進這個久經考驗的產品。

H201TI?4

The HydranTM 201Ti is a small and easy to setup continuous Dissolved Gas-in-oil Analysis (DGA) monitor.
It provides the basic information used by IEEE? Standard C57.104 and can be used as an essential first
line of defence for the transformers in your fleet to obtain advance warning of a failure condition and
minimize the risk of unplanned outages.
The 201Ti’s composite-gas sensor provides the world renown “Hydran gas value” using fuel cell
technology (described as fixed instruments – method 3 in the standard). It responds 100% to Hydrogen
(general fault gas) and is also sensitive to Carbon Monoxide (overheated paper), Acetylene (arcing) and
Ethylene (overheated oil), thus covering all the main transformer failure root causes.
Because the monitoring unit mounts on a single valve and uses Dynamic Oil Sampling, there is no
need for a pump or extra piping to connect to different valves. Due to its uncomplicated features and
the easily understood information it provides, the 201Ti has been amongst the monitors of choice for
many years, with one of the largest installed base of any monitor.
With the latest Mark IV version, the Hydran 201Ti monitor has been completely overhauled with new
electronic boards and power supply to make it RoHS compliant, address any obsolescence issue and
further improve this time proven product.

H201TI?4
