IC695CPU315是GE Fanuc PACSystems RX3系列的1 GHZ中央處理器。它有一個英特爾賽場-M微處理器，帶有20 MB用戶內存(也稱為隨機存取存儲器或RAM)和20 MB閃存。作為可編程控制器，1C695CPU315每秒能夠進行高達32K的/0操作。它最多支持512個程序塊，每個程序塊的最大大小為128 KB。IC695CPU315使用雙背板總線與I/O和智能選項模塊通信。

IC695CPU315

像這樣的RX3iCPUs是為機器、過程和材料處理系統的實時控制而設計的。它們可以用語言編程，或者用IEC(國際電工委員會)認可的五種編程語言中的二種編程，從IEC語言列表中，您可以使用梯形邏輯(梯形圖)、結構化文本或功能準圖語言對IC695CPU315進行編程，只有順序功能圖和指令列表語言選項不適用。
C695CPU315采用浮點算法，其固件可以在系統內升級、自動定位的符號變量可以根據需要使用任意多的內存，最多可以使用20 MB的用戶內有CPU出廠時配置有兩個正面端口，一個R5-485串行端口和一個R5-232串行端口。因此，您有一個9計連接器和-個15計連接器。CPU支持SNP串行//0以及Modbus從和主串行協議。IC695CPU315還支持大多數較舊的GE Fanuc系列90-30模塊和擴展機架。

IC695CPU315

The IC695CPU315 is a 1 GHZ CPU from the GE Fanuc PACSystems RX3 series. It has an Intel Stadium-M microprocessor with 20 MB of user memory (also known as random access memory or RAM) and 20 MB of flash memory. As a programmable controller, 1C695CPU315 is capable of up to 32K /0 operations per second. It supports up to 512 blocks, each with a maximum size of 128 KB. The IC695CPU315 uses a dual-backplane bus to communicate with the I/O and Smart Options modules.
RX3iCPUs like this one is designed for real-time control of machines, processes and material handling systems. They can be programmed in languages, or in two of the five programming languages recognized by the IEC(International Electrotechnical Commission), from the list of IEC languages, you can program the IC695CPU315 using ladder logic (ladder diagram), structured text, or function diagram languages, only the sequential function diagram and instruction list language options do not apply.
The C695CPU315 uses a floating point algorithm, its firmware can be upgraded within the system, the automatic positioning of symbol variables can use as much memory as needed, up to 20 MB of user can use the CPU factory configured with two front ports, one R5-485 serial port and one R5-232 serial port. So you have one 9-meter connector and one 15-meter connector. The CPU supports SNP serial //0 as well as Modbus slave and master serial protocols. The IC695CPU315 also supports most older GE Fanuc series 90-30 modules and expansion racks.

IC695CPU315
