IC698CMX016 是 PACSystems RX7i 控制內存交換模塊，由艾默生自動化（以前由 GE 智能平臺 (GE IP)）制造。該模塊用于通過光纖網絡在 PLC 之間共享確定性數據。該模塊是一個單插槽模塊，具有 16 MB 反射內存，具有奇偶校驗功能。它有一個專為 LC 型連接器設計的光纖端口，支持 2.12 Gbaud 數據傳輸。該模塊支持通過 FO 電纜的菊花鏈連接最多連接 256 個節點。

IC698CMX016 是來自可編程自動化控制器 (PAC) 的 PACSystem RX7i 平臺的控制內存交換模塊。該組件本質上是一個內存模塊，但是 IC698CMX016 的主要功能是使用反射內存技術通過光纖網絡在 PLC 和兼容設備之間提供確定性的數據共享。

IC698CMX016 的通信接口包括一個 LC 光纖端口，支持多模光纖介質上 2.12 Gbaud 的傳輸速度，最大距離為 300 米或 984.25 英尺 支持的動態數據包大小范圍為 4-64 字節，最大網絡傳輸速率為 43 MB 4 字節數據包中的 / 秒到 64 字節數據包中的 174 MB / 秒。該內存模塊能夠與每個網絡多達 256 個節點進行通信，并支持冗余傳??輸模式操作。
C698CMX016是可編程自動化控制器(PA)PAC system RX7平臺的控制存儲器交換模塊。該組件本質上是一個存儲模塊，但I(xiàn)C698CMX016的主要功能是使用反射存儲技術在光纖網絡上的PLC和兼容設備之間提供確定性的數據共享.
該模塊配有16 MB SDRAM的奇便校驗反射內存。它安裝車RX7湖架上，占據背板的一個插博。該模塊獨立于CPU，因?yàn)樗恍枰魏蜟PU處理來運行。此外，它與VMIC 5565系列反射式存儲設備網絡兼容
C698CMX016的通信接口包括一個LC光纖端口，在多模光纖個質上支持212 Gbaud的傳速度，最大距離為300米或984.25英尺，支持的動態數據包大小范圍為4-64字節，最大網絡傳輸速率為43兆字節/(4字節數據包)至174兆字節/秒64字節數據包)。該內存模塊能夠與每人網絡多達256人節點進行通信，并支持冗余傳輸模式操作。

IC698CMX016-ED

C698CMX016前面板配有各種LED狀態指示器，如OK、CONFG、OWN DATASIGNAL DETECT，要利用IC698CMX016的功能，必須將其安裝在帶有2.00版或更高版本固件的s RX7iCPU、帶電源的RX7CPU機架上，并使用ProFicy Machine Edition-loic Developer PLC 4.5版或更高版本進行配置。
GE FanuC1C698CMX016通信模塊是Rx7i系統的控存儲器本換或CMX模塊，該模在1C和高速光纖網絡反時式有烤系統上連接的現場設各之提供預編程數據共享，IC698CMX016模塊可以在單個反射內存網絡中容納多達256個節點，并且它與連接到每個節點的VMIC 5565系列反射內存設備兼容。每個VMIC 5565設備通過光以菊花鏈環路的形式連接到212 GBaud光纖網絡，1C698CMX016通信模塊可以在每秒43兆字節(4字節動本數據包大)到每秒174兆字節(64字節動態數據包大小)的可配置傳輸范圍內傳輸現場數據，它具有16 MB的用戶存儲器(SDRAM)和來自機器版(ME邏輯開發PLC的可靠軟件配置，版本4.5或更高版本的軟件
GE Fanuc 1C698CMX016模塊的額定電壓為5,.0優DC，最大工作電流為1,8安培，在IC698CMX016模塊的前面板上，有一個光收發器，帶有兩人標記為T(mén)X和RX的光纖端口，用于發送和接收現場數據。C698CMX016模塊提供用戶可配置的VME總線輸出，通過它啟動網絡數據傳輸，它還提供網絡錯誤檢測，以實現平穩的數據傳輸，IC698CMX016模塊安裝在Rx71 PACsystem l/0機架的單個插槽中，它帶有4個前面板狀態/診斷l(xiāng)ed，分別是OK CONFIG、OWN DATA和SIGNAL DETECT LEDS，用于顯示模塊的操作和通信狀態。

The IC698CMX016 is a PACSystems RX7i control memory switch module manufactured by Emerson Automation (formerly GE Intelligent Platform (GE IP)). The module is used to share deterministic data between PLCS over a fiber optic network. The module is a single slot module with 16 MB of reflected memory with parity. It has a fiber optic port designed for LC type connectors and supports 2.12 Gbaud data transfer. The module supports the connection of up to 256 nodes through the Daisy chain connection of the FO cable.

The IC698CMX016 is a control memory switch module for the PACSystem RX7i platform from the Programmable Automation Controller (PAC). The component is essentially a memory module, but the main function of the IC698CMX016 is to provide deterministic data sharing between the PLC and compatible devices over a fiber optic network using reflected memory technology.

The IC698CMX016 communication interface includes an LC fiber port that supports 2.12 Gbaud transfer speeds over multimode fiber media, a maximum distance of 300 meters or 984.25 feet, and supports dynamic packet sizes ranging from 4 to 64 bytes. Maximum network transfer rates range from 43 MB/s in 4-byte packets to 174 MB/s in 64-byte packets. The memory module is capable of communicating with up to 256 nodes per network and supports redundant transmission mode operation.
The C698CMX016 is a control memory switch module for the Programmable Automation Controller (PA)PAC system RX7 platform. The component is essentially a storage module, but the main function of the IC698CMX016 is to provide deterministic data sharing between PLCS and compatible devices on a fiber optic network using reflective storage technology.
The module is equipped with 16 MB SDRAM of odd-check reflected memory. It mounts on the car RX7 lake rack, occupying the backplane of a plug-in. This module is CPU independent because it does not require any CPU processing to run. In addition, it is compatible with the VMIC 5565 series reflective storage device network
The communication interface of the C698CMX016 includes an LC fiber port that supports 212 Gbaud speeds over multimode fiber masses over a maximum distance of 300 meters or 984.25 feet, and supports dynamic packet sizes ranging from 4 to 64 bytes. Maximum network transfer rates range from 43 megabytes /(4-byte packets) to 174 megabytes/second (64-byte packets). The memory module is capable of communicating with up to 256 person nodes per person network and supports redundant transport mode operation.
The C698CMX016 front panel is equipped with various LED status indicators, such as OK, CONFG, OWN DATASIGNAL DETECT, to take advantage of the functions of IC698CMX016, It must be installed on an s RX7iCPU with firmware version 2.00 or later, an RX7CPU rack with power supply, and configured using ProFicy Machine Edition-loic Developer PLC version 4.5 or later.
The GE FanuC1C698CMX016 communication module is the Rx7i system’s control memory exchange or CMX module, which provides pre-programmed data sharing between the field devices connected on the 1C and high-speed fiber optic network, and the IC698CMX016 module can accommodate up to 256 nodes in a single reflective memory network. And it is compatible with the VMIC 5565 series reflective memory devices connected to each node. Each VMIC 5565 device is connected to a 212 GBaud fiber network via optical Daisy chain loop, and the 1C698CMX016 communication module can transmit field data in a configurable transmission range of 43 megabytes per second (4 bytes of dynamic data packet size) to 174 megabytes per second (64 bytes of dynamic data packet size). It has 16 MB of user memory (SDRAM) and reliable software configuration from the Machine Edition (ME Logic Development PLC, software version 4.5 or later
The GE Fanuc 1C698CMX016 module has a voltage rating of 5,.0 excellent DC and a maximum operating current of 1,8 amps. On the front panel of the IC698CMX016 module, there is an optical transceiver with two optical fiber ports labeled TX and RX for sending and receiving field data. The C698CMX016 module provides a user-configurable VME bus output through which network data transmission is initiated, it also provides network error detection for smooth data transmission, the IC698CMX016 module is installed in a single slot in the Rx71 PACsystem l/0 rack, and the IC698CMX016 module is also installed in a single slot in the RX71 PACSystem L /0 rack. It comes with 4 front panel status/diagnostic LEDS, namely OK CONFIG, OWN DATA and SIGNAL DETECT LEDS, which are used to display the module’s operation and communication status.

IC698CMX016-ED
