通用電氣開發的IS200TREGH1BDC是一種緊急跳閘終止板，是Mark VI系列的一部分。這個板有12個繼電器，也被稱為接觸器，它們排成兩排，每排6個。繼電器是白色和黑色的，一根銀色金屬線位于每個繼電器的頂部。除了位于頂部邊緣的三個白色跳線端口外，金屬氧化物壓敏電阻也填充板。其中一個連接器具有三個端口，另一個包含十二個和兩個小端口。電路板上還有許多小型集成電路，它們?cè)谶@些較大電路的右側排成一長排。在板的左側邊界上是兩個端子塊，兩個端子塊都包含從1到48的金屬端子。
IS200TREGH1BDC
The IS200TREGH1BDC developed by GE is an emergency trip termination board that is part of the Mark VI series. The board has 12 relays, also known as contactors, arranged in two rows of six each. The relays are white and black, with a silver metal wire at the top of each relay. In addition to the three white jumper ports located on the top edge, metal oxide varistors also fill the plates. One of the connectors has three ports, and the other contains twelve and two small ports. There are also many small integrated circuits on the board, which are arranged in a long row to the right of these larger circuits. On the left boundary of the board are two terminal blocks, both containing metal terminals from 1 to 48.
IS200TREGH1BDC
