IS220PAICH1A型號被描述為模擬I/O包，已被批準用于危險和非危險場所。在模型的正面，有四個指標。底部還有一個端口，它被描述為I/O端口。有幾種電壓可以與PAIC包一起使用，PAIC包的最小電壓是27.4伏的直流電。
有各種認證與IS220PAICH1A包有關，因?yàn)樗哪芰梢栽谠S多地點使用，其中一些是危險地點，一類區二組IIC，一類區二組a, B, C, D，和ATEX區二，組IIC和非危險地點。以下認證用于地點，UL E207685和UL DEMKO 12 ATEX 1114875X，請注意UL E207685認證用于許多地點。
IS220PAICH1A
有三種型號可以與IS220PAICH1A單元一起使用，即IS200STAIH1A和IS200STAIH2A以及IS20TBAIH1C型號。所有這些型號都被稱為輸入輸出端子板。
pac I/O包的典型位置是在兩個可用的VME機架中的一個，即13個或21個插槽機架。請注意，該單元通常將與三重模塊化冗余架構系統一起使用。在TMR系統中，有獨立的控制模塊、I/O網絡和主處理器卡。
IS220PAICH1A
The IS220PAICH1A model is described as an analog I/O package that has been approved for use in hazardous and non-hazardous locations. On the front side of the model, there are four indicators. There is also a port on the bottom, which is described as an I/O port. There are several voltages that can be used with the PAIC package, the minimum voltage of the PAIC package is 27.4 volts of direct current.
There are various certifications associated with the IS220PAICH1A package because its capabilities can be used in many locations, some of which are hazardous locations, Zone 1 Group II Iics, Zone 1 Group II a, B, C, D, and ATEX Zone 2, Group Iics and non-hazardous locations. The following certifications are used for locations, UL E207685 and UL DEMKO 12 ATEX 1114875X, please note that UL E207685 certifications are used for many locations.
There are three models that can be used with the IS220PAICH1A unit, namely the IS200STAIH1A and IS200STAIH2A and the IS20TBAIH1C model. All of these models are referred to as input/output terminals.
The typical location for pac I/O packets is in one of the two available VME racks, i.e. 13 or 21 slot racks. Note that this unit will typically be used with a triple modular redundant architecture system. In the TMR system, there are independent control modules, I/O networks and main processor cards.
