IS220PRTDH1A是通用電氣公司的電阻溫度器件輸入模塊。該模塊是GE Mark VIe Speedtronic系統的一部分，該系統是最后可用的Speedtronic系統之一。Speedtronic系列由通用電氣在20世紀60年代創建，用于管理工業燃?xì)夂驼羝麥u輪機，包括Mark I, Mark II, Mark IV和Mark VI等流行版本。

IS220PRTDH1A是一個I/O包，設計用于與終端板一起工作。當與IS200TRTDH2D, IS200SRTDH1A或IS200SRTDH2A等特定端子板一起使用時，它被批準在危險場所使用。這臺機器有自己的電源。

IS220PRTDH1B

只有像RTD這樣的簡單電阻設備才應該連接到IS220PRTDH1A上的RTD輸入端。用于這些連接的電纜應按照當?shù)仉姎庖?guī)范的規定具有適當?shù)慕^緣。

IS220PRTDH1A的前面板包括I/O單元的兩個以太網端口的LED指示燈，以及電源和ATTN LED指示燈。端口位于設備的側面。
在添加任何種類的包裝材料之前，該單元的重量約為4.40磅。尺寸為34 x 18 x 10厘米。該裝置有CE標志和UL認證。

IS220PRTDH1B

The IS220PRTDH1A is a General Electric resistance temperature device input module. The module is part of the GE Mark VIe Speedtronic system, one of the last Speedtronic systems available. The Speedtronic family was created by General Electric in the 1960s to manage industrial gas and steam turbines, including popular versions such as the Mark I, Mark II, Mark IV and Mark VI.

The IS220PRTDH1A is an I/O package designed to work with the terminal board. When used with specific terminal boards such as IS200TRTDH2D, IS200SRTDH1A or IS200SRTDH2A, it is approved for use in hazardous locations. The machine has its own power supply.

Only simple resistance devices like RTDS should be connected to the RTD input on the IS220PRTDH1A. The cables used for these connections shall have appropriate insulation as specified in the local electrical code.

The front panel of the IS220PRTDH1A includes LED indicators for two Ethernet ports on the I/O unit, as well as power and ATTN LED indicators. Ports are located on the side of the device.
Before adding any kind of packaging material, the unit weighs about 4.40 pounds. The dimensions are 34 x 18 x 10 cm. The device is CE marked and UL certified.

IS220PRTDH1B
