IS220UCSAH1A是通用電氣為Mark VI系統創建的處理器/控制器。Mark VI平臺設計用于管理燃?xì)饣蛘羝啓C(jī)，由GE公司發布，作為Speedtronic生產線的一部分。它的特點是一個HMI(人機界面)與軟件設計運行重型渦輪機，如簡單圖形界面。

IS220UCSAH1A被建造為一個單一的盒裝組件，具有一個前面板允許通信連接，兩個螺釘安裝在后邊緣，和三面格柵開口允許空氣流動。該控制器是為安裝在機柜內而設計的。多達三個組件可以彼此相鄰地安裝，以實現緊湊的布置，輕松地服務于三重冗余系統。

IS220UCSAH1A

IS220UCSAH1A在QNX操作系統上工作。它有一個飛思卡爾8349,667mhz的處理器。電路板使用額定18- 36v直流，12瓦的電源。該板可以在0到65攝氏度的溫度下使用，即使在最高額定溫度下，也不需要風扇進行冷卻。該板可用于NFPA Class 1, Div. 2應用。

IS220UCSAH1A前面板有6個母插座，1個USB接口，多個LED指示燈。這包括標有Link/Act的前面板左側的LED指示燈，以及位于面板中間的一系列標有Power, Boot, Online, Flash, DC和Diag的指示燈。插孔連接器用于以太網連接，使電路板能夠與其他MKVI, MKVIe或EX2100勵磁控制以及維護站和操作站進行通信。

IS220UCSAH1A

The IS220UCSAH1A is a processor/controller created by General Electric for the Mark VI system. The Mark VI platform, designed to manage gas or steam turbines, was released by GE as part of the Speedtronic line. It features an HMI(Human Machine Interface) with software designed to run heavy duty turbines, such as a simple graphical interface.

The IS220UCSAH1A is built as a single boxed assembly with a front panel allowing communication connections, two screws mounted on the back edge, and three-sided grille openings allowing air flow. The controller is designed for installation in the cabinet. Up to three components can be installed next to each other for a compact arrangement that easily serves triple redundant systems.

The IS220UCSAH1A works on the QNX operating system. It has a Freescale 8349,667mhz processor. The board uses a 12-watt power supply rated at 18-36v DC. The board can be used at temperatures ranging from 0 to 65 degrees Celsius and does not require a fan for cooling, even at the highest rated temperature. The board can be used for NFPA Class 1, Div.2 applications.

The IS220UCSAH1A front panel has 6 female sockets, 1 USB port, and multiple LED indicators. This includes LED indicators labeled Link/Act on the left side of the front panel, and a series of indicators labeled Power, Boot, Online, Flash, DC, and Diag located in the middle of the panel. The jack connector is used for Ethernet connectivity and enables the board to communicate with other MKVI, MKVIe or EX2100 excitation control as well as maintenance and operation stations.

IS220UCSAH1A
