MVI56-PDPS PROSOFT 通信網絡接口模塊

MVI系列中的所有模塊都使用可充電的五氧化二釩鋰電池
備份512K SRAM內存、實時時鐘、CMOS。電池應該可以使用
模塊的壽命。
該模塊必須通電大約20小時才能充滿電
起訴。充滿電后，電池為CMOS設置提供備用電源
和配置數據，實時時鐘，以及512K SRAM內存
大約21天。
從電源拔出模塊前，請確認模塊內的電池沒有損壞
模塊已充滿電。一個充滿電的電池將保持BIOS設置(經過)
從其電源中移除)，時間有限(PC56為15天)。當
電池完全放電后，模塊將恢復到默認的BIOS設置。

MVI56-PDPS

軟件組件:
羅克韋爾自動化ControlLogix?處理器，具有兼容的電源
電源和機架上的一個免費插槽，用于MVI56-PDPS模塊。的
模塊需要800mA的可用功率。
羅克韋爾自動化RSLogix 5000編程軟件版本2.51或
更高。
羅克韋爾自動化RSLinx通信軟件
奔騰?II最低450mhz。Pentium III 733 MHz(或更高)
推薦
支持的操作系統:
o Microsoft Windows XP Professional with Service Pack 1或2
o Microsoft Windows 2000 Professional(含Service Pack 1、2或3)
o Microsoft Windows Server 2003
最少128 mb的RAM，建議256 mb的RAM
MVI56-PDPS模塊的示例程序包括自定義標記、數據
數據I/O和狀態監控的類型和階梯邏輯。對于大多數應用程序，
您可以在不修改的情況下運行示例階梯程序，也可以使用高級程序
應用程序，您可以將示例程序合并到您現有的
應用程序。
附加在文件名后的版本號與固件對應
ControlLogix處理器的版本號。固件版本和
樣例程序版本必須匹配。

MVI56-PDPS

All modules in the MVI series use rechargeable lithium vanadium pentoxide batteries
Back up 512K SRAM memory, real-time clock, CMOS. The battery should work
Lifetime of the module.
The module must be powered on for about 20 hours to be fully charged
Sue. When fully charged, the battery provides backup power for the CMOS setup
And configuration data, real-time clock, and 512K SRAM memory
About 21 days.
Before removing the module from the power supply, ensure that the battery in the module is not damaged
The module is fully charged. A fully charged battery will keep BIOS Settings (through)
Removed from its power supply) for a limited time (15 days for PC56). when
After the battery is fully discharged, the module reverts to the default BIOS Settings.
The minimum hardware requirements of the MVI56-PDPS module are as follows
Software components:
Rockwell Automation ControlLogix? processor with compatible power supply
Power supply and a free slot in the rack for the MVI56-PDPS module. the
The module requires 800mA of available power.
Rockwell Automation RSLogix 5000 Programming software version 2.51 or
Higher.
Rockwell Automation RSLinx communication software
Pentium ?II starts at 450mhz. Pentium III 733 MHz(or higher)
Recommended
Supported operating systems:
o Microsoft Windows XP Professional with Service Pack 1 or 2
o Microsoft Windows 2000 Professional(with Service Pack 1, 2, or 3)
o Microsoft Windows Server 2003
Minimum 128 mb of RAM, 256 mb of RAM recommended
Sample programs for the MVI56-PDPS module include custom tags, data
Types and ladder logic for data I/O and status monitoring. For most applications,
You can run the example ladder program without modification, or you can use the advanced program
Application, you can incorporate sample programs into your existing ones
The application.
The version number appended to the file name corresponds to the firmware
ControlLogix processor version number. Firmware version and
The sample program version must match.
