盡管 NI 9234 模塊具有較高的認證標準，當它與 NI USB-9162 外盒配合使用時，系統
滿足的標準受各組件限制。詳細信息見產品規范。
注意 該符號表明組件表面溫度較高，觸摸該組件可能導致受傷。
注意 電源未斷開或處于非安全環境時，請勿斷開 I/O 連線或連接器。
注意 電源未斷開或處于非安全環境時，請勿卸除模塊。
注意 NI USB-9234 未通過用于危險環境的認證。
如連接危險電壓至模塊，需采取下列防護措施。危險電壓是指峰值電壓高于
42.4 Vpk 的交流電壓或高于 60 VDC 的直流電壓。
注意 確保危險電壓的連接由具有當?shù)仉姎獍踩Y質的專業人士完成。
注意 請勿將危險電壓電路和人體可接觸電路放置在同一模塊內。
注意 確保連接至模塊的設備和電路與人體接觸有效隔離。
每套應用軟件包和驅動程序都包括完成測量和控制測量設備的編程信息。
下列參考文檔假定用戶已安裝 NI-DAQmx 8.8 或更高版本，如使用 NI 應用
軟件，其版本應為 7.1 或更高。

NI-9234

如在 Measurement Studio 中使用 Visual C++、 Visual C#、
Visual Basic .NET 對 NI-DAQmx 支持的設備編程，可在 MAX 或
Visual Studio .NET 中打開 DAQ 助手，交互式地創建通道和任務。在
Measurement Studio 中，可根據任務或通道生成配置代碼。關于生成
代碼的詳細信息，見 DAQ 助手幫助?；蛘咴趹?yīng)用程序開發環境 (ADE) 中
使用 NI-DAQmx API 創建通道和任務。

NI-9234

Although the NI 9234 module has a high certification standard, when it is used in conjunction with the NI USB-9162 outer box, the system
The standards that can be met are limited by the components. See Product Specification for details.
Note that this symbol indicates that the surface temperature of the component is high and that touching the component may result in injury.
Caution Do not disconnect I/O cables or connectors when the power supply is not disconnected or in an unsafe environment.
Caution Do not remove the module when the power supply is not disconnected or in an unsafe environment.
Note that NI USB-9234 is not certified for use in hazardous environments.
If a dangerous voltage is connected to the module, the following precautions should be taken. Dangerous voltage means peak voltage is higher than
Ac voltage of 42.4 Vpk or DC voltage higher than 60 VDC.
Take care to ensure that hazardous voltage connections are made by professionals with local electrical safety qualifications.
Do not place the dangerous voltage circuit and the human body accessible circuit in the same module.
Take care to ensure that devices and circuits connected to the module are effectively isolated from human contact.
Each application package and driver includes programming information to complete the measurement and control the measurement device.
The following reference documents assume that you have Ni-DAQMX 8.8 or higher installed, if you are using NI applications
Software, whose version should be 7.1 or higher.

For example, Visual C++, Visual C#,
Visual Basic.NET for Ni-DAQMX-supported device programming, available at MAX or
Open the DAQ assistant in Visual Studio.NET to interactively create channels and tasks. in
In Measurement Studio, configuration code can be generated by task or channel. About generation
For details of the code, see DAQ Assistant Help. Or in an application development environment (ADE)
Create channels and tasks using the NI-DAQmx API.

NI-9234
