PROFIBUS DPV1主控模塊是一個功能強大的通信接口
量子處理器。該模塊由施耐德電氣授權開發
采用專有背板技術，實現強大的數據交換
與處理器。
該模塊支持根據IEC 61158完整的主規范。無環
參數數據可以用1類或2類DPV1服務傳輸，允許
處理器可以輕松地與支持PROFIBUS DPV0/V1的從設備通信
協議。
該模塊作為PROFIBUS網絡和總線之間的輸入/輸出模塊
處理器。來自處理器的數據傳輸與I/O數據傳輸是異步的
在PROFIBUS網絡上。

PTQ-PDPMV1

易于配置和管理?包括ProSoft配置生成器軟件來設計，配置和監控您的
現場總線網絡
?包括PROFIBUS DPV1 Master FDT (Field Device Tool)通信DTM
(PROFIBUS comDTM)軟件之間的接口，任何兼容的FDT軟件容器，
一個FDT設備DTM，以及適用的PROFIBUS從設備
通過以太網配置PTQ模塊和PROFIBUS網絡
行業認可?施耐德電氣CAPP(協同自動化合作伙伴計劃)批準
PROFIBUS貿易組織(PTO)認證
堅固可靠?該模塊基于西門子ASIC ASPC2 Step E和英飛凌C165微處理器
?固件支持flash升級
?符合Unity HEC熱備功能規范。
每個機架最多支持6個PTQ-PDPMV1模塊(熱備時最多支持4個
實現)
?支持?jǐn)U展的診斷數據，報警指示和確認處理，多播
及廣播電報(DPV1)
由ProSoft Technology?支持
工業數據通信專家，了解您的協議，設備和
應用程序

PTQ-PDPMV1

The PROFIBUS DPV1 Master module is a powerful communication interface for
Quantum processors. Developed under license from Schneider Electric, the module
incorporates proprietary backplane technology that enables powerful data exchange
with processors.
The module supports complete Master specifications according to IEC 61158. Acyclic
parameter data can be transferred with Class 1 or Class 2 DPV1 services, allowing
processors to easily communicate with slave devices supporting PROFIBUS DPV0/V1
protocol.
The module acts as an input/output module between the PROFIBUS network and the
processor. Data transfer from the processor is asynchronous with the I/O data transfer
on the PROFIBUS network.

Easy to configure and manage ? Includes ProSoft Configuration Builder software to design, configure and monitor your
PROFIBUS network
? Includes PROFIBUS DPV1 Master FDT (Field Device Tool) communication DTM
(PROFIBUS comDTM) software to interface between any compliant FDT software container,
an FDT device DTM, and applicable PROFIBUS slave devices
? Configure PTQ module and PROFIBUS network over Ethernet
Industry Recognition ? Schneider Electric CAPP (Collaborative Automation Partner Program) approved
? PROFIBUS Trade Organization (PTO) approved
Rugged and reliable ? The module is built on Siemens ASIC ASPC2 Step E with Infineon C165 Microprocessor
? The firmware is flash-upgradable
? Adheres to the Unity HEC Hot Standby Functional Specifications.
? Supports up to six PTQ-PDPMV1 modules per rack (up to four for Hot Standby
implementations)
? Supports extended diagnostic data, alarm indications and confirmations handling, Multicast
and Broadcast telegrams (DPV1)
Backed by ProSoft Technology?
? Industrial data communications experts who understand your protocols, devices, and
applications

PTQ-PDPMV1
