配置:
?處理器:1.8GHz奔騰M
?DDR內存:1gb
?二級緩存:2MB
?Flash: 512kb
?1101.10前面板
?可選G1千兆前面板以太網接口
?RC:符合RoHS標準

部件編號:350-93007807-420001
產品系列:598-01-6 32-8857、5998016328857
特點:
1.1GHz、1.4GHz或1.8 GHz奔騰M處理器
高達2 MB的二級緩存
DDR同步SDRAM
最大1.5GB SDRAM
雙千兆以太網
高達2GB可啟動的CompactFlash
Abaco Systems / VMIC VME-7807系列單板計算機工廠配備1.1,1.4或1.8GHz奔騰M處理器，最高可達2 MB L2緩存。VME-7807RC SBC提供DDR同步DRAM (SDRAM)作為板載系統內存。這些SBC接受一個200引腳DDR SDRAM SODIMM以及可選的焊接512MB板載內存，最大容量為1.5GB。這些SBC還具有雙千兆以太網和高達2GB可啟動的CompactFlash。
VMIVME-7807是下一代6 U單槽VME單板計算機（SBC），它集成了英特爾奔騰M處理器和高達1.5 GB的DDR SDRAM、一個PCI-X、66 MHz PMC擴展槽、雙千兆以太網和高達1 GB的CompactFlash內存
。
該SBC的工作頻率高達1.8 GHz，提供高帶寬和處理能力，非常適合I/O密集型應用。該產品提供兩種不同的雙千兆以太網配置。在第一種配置中，一個10/100/1000BaseT以太網端口連接到前面板，另一個連接到后P2連接器。在第二種配置中，兩個10/100/1000BaseT以太網端口都被路由到后面的P0連接器，以支持VITA 31.1（VME 64 x背板上的千兆以太網）。

VMIVME-7807

VMIVME-7807

Settings:
? Processor :1.8GHz Pentium M
?DDR memory :1gb
? Level 2 cache :2MB
?Flash: 512kb
?1101.10 Front Panel
? Optional G1 Gigabit Ethernet port on the front panel
?RC: RoHS compliant

Part number :350-93007807-420001
Product series: 598-01-632-8857, 5998016328857
Features:
1.1GHz, 1.4GHz, or 1.8 GHz Pentium M processors
Up to 2 MB of level 2 cache
DDR synchronizes SDRAM
Max. 1.5GB SDRAM
Dual Gigabit Ethernet
Up to 2GB of bootable CompactFlash
Abaco Systems/VMIC VME-7807 series single-board computers are factory equipped with 1.1,1.4 or 1.8GHz Pentium M processors with up to 2 MB L2 cache. The VME-7807RC SBC provides DDR synchronous DRAM (SDRAM) as on-board system memory. These SBCS accept a 200-pin DDR SDRAM SODIMM as well as an optional welded 512MB of on-board memory with a maximum capacity of 1.5GB. These SBCS also feature dual gigabit Ethernet and up to 2GB bootable CompactFlash.
The VMIVME-7807 is a next-generation 6 U single-slot VME single-board computer (SBC) that integrates an Intel Pentium M processor with up to 1.5 GB of DDR SDRAM, a PCI-X, 66 MHz PMC expansion slot, dual Gigabit Ethernet, and up to 1 GB of CompactFlash memory
.
Operating at frequencies up to 1.8 GHz, the SBC provides high bandwidth and processing power, making it ideal for I/ O-intensive applications. The product offers two different dual Gigabit Ethernet configurations. In the first configuration, one 10/100/1000BaseT Ethernet port is connected to the front panel and the other is connected to the rear P2 connector. In the second configuration, both 10/100/1000BaseT Ethernet ports are routed to the rear P0 connector to support VITA 31.1 (Gigabit Ethernet on the VME 64 x backplane).
