XVME-653是Xycom Automation公司的一款功能強大的VMEbus PC兼容處理器模塊，也是VMEbus PC技術的先驅和領導者。
這強大的單槽VMEbus處理器集成了233 MHz MMX奔騰CPU，帶PCI到VMEbus接口，允許用戶采用優勢在于強大的多處理能力的VMEbus，同時使用標準現貨PC軟件和操作系統。XVME-653模塊的核心是Intel233MHz MMX CPU結合512K同步2級管道緩存和高達256 MB的內存快頁或EDO DRAM。該模塊包含廣泛的I/O，包括PCI圖形、EIDE和以太網控制器，一個通用串行總線(USB)接口，兩個高速串口，一個EPP/ECP并口，PS/2樣式鍵盤和鼠標端口。

XVME-653模塊的核心是英特爾233MHz MMX CPU，結合512K同步二級管道高速緩存和高達256 MB的快頁或江戶DRAM。該模塊包含廣泛的I/O，包括PCI圖形、EIDE和以太網控制器，一個通用串行總線(USB)端口，兩個高速串行端口、一個EPP/ECP并行端口和PS/2風格鍵盤和鼠標端口。使用Xycom Automation的模塊化，可以進一步擴展I/OI/O載體模塊(XVME-976)，提供使用PMC擴展系統的機制，PC/104、短ISA或PCI模塊。XVME-653模塊是無與倫比的解決方案單槽VMEbus模塊上的電源和I/O。

XVME-653

XVME-653 is a powerful VMEbus PC-compatible processor module from Xycom Automation and a pioneer and leader in VMEbus PC technology.
This powerful single-slot VMEbus processor integrates a 233 MHz MMX Pentium CPU with a PCI to VMEbus interface, allowing users to take advantage of the VMEbus’s powerful multiprocessing capabilities while using standard off-the-shelf PC software and operating systems. At the heart of the XVME-653 module is an Intel233MHz MMX CPU combined with 512K synchronous level 2 piped cache and up to 256 MB of memory fast page or EDO DRAM. The module includes a wide range of I/O, including PCI graphics, EIDE and Ethernet controllers, a universal serial bus (USB) interface, two high-speed serial ports, an EPP/ECP parallel port, PS/2 style keyboard and mouse ports.

At the heart of the XVME-653 module is an Intel 233MHz MMX CPU, combined with 512K synchronous secondary pipeline cache and up to 256 MB of fast page or Edo DRAM. The module includes a wide range of I/ OS, including PCI graphics, EIDE and Ethernet controllers, a universal serial bus (USB) port, two high-speed serial ports, an EPP/ECP parallel port, and PS/2 style keyboard and mouse ports. Using Xycom Automation’s modularity, it is possible to further extend the I/OI/O carrier module (XVME-976), providing a mechanism to extend the system using PMC, PC/104, Short ISA, or PCI modules. The XVME-653 module is the unmatched solution for power and I/O on single slot VMEbus modules.

XVME-653
