零件號碼:8715-CA-BI
底板:當用作遠程I/O時，PAC8000節 點使用總線接口模塊(IM)通過局域網(L AN)與主機控制器通信。根據其功能，BIM以多種不同的封裝形
式提供，每種都安裝在專用的BIM載體上。
特征
●PAC8000 /O是完全模塊化的I/O解決方案，適用于通用和危險區域應用。它提供各種I/O功能，犋有開放式架構，通過選擇適當類型的總
線接口模塊(BIM)或控制器，允許與各種不同的現場總線進行通信。
●現場端子(每個I/O模塊一 個)卡在載體上,無需額外的端子或連接即可接受現場接線。如果在現場損壞，可以很容易地更換它們。全面的機械
鍵控系統確保了設備的安全性。
●載體通過安裝在平板或T或G截面DIN導軌 上形成PAC8000s的物理和電氣注干。它們支持并互連BIM或控制器、電源、/O模塊和現場終端,
并承載內部軌道總線的地址、數據和電源線

8715-CA-BI

Part number :8715-CA-BI
Backplane: When used as remote I/O, the PAC8000 nodes use a bus interface module (IM) to communicate with the host controller over a local area network (LAN). Depending on its function, BIM comes in a number of different packages
Each is installed on a dedicated BIM carrier.
trait
The PAC8000 /O is a fully modular I/O solution for general purpose and hazardous area applications. It offers a variety of I/O functions, 犋 has an open architecture, by selecting the appropriate type of total
Line interface modules (BIM), or controllers, allow communication with a variety of different fieldbuses.
● Field terminals (one per I/O module) are stuck to the carrier and can accept field wiring without additional terminals or connections. If damaged in the field, they can be easily replaced. Complete machinery
The keying system ensures the safety of the equipment.
● The carrier is physically and electrically injected to form PAC8000s by mounting on a flat plate or T or G section DIN rail. They support and interconnect BIM or controllers, power supplies, /O modules and field terminals,
It also carries the address, data, and power lines of the internal track bus
