IS220PDIAH1A是通用電氣制造的離散輸入模塊，是用于燃?xì)廨啓C控制系統的 Mark VIe 系列的一部分。一個或兩個 I/O 以太網網絡與離散輸入端子板之間的電氣連接由離散輸入 (PDIA) 包提供。該組件支持多達 24 個觸點輸入，以及特定于端子板和 PDIA的反饋信號。帶有電壓感應的 TICI 型隔離離散輸入板的連接。
IS220PDIAH1A I/O 包或模塊功能特定的采集板連接到處理器板。當施加輸入電源時，軟啟動電路會逐漸升高處理器板上的可用電壓。處理器復位關閉，本地電源按順序打開。完成自檢例程后，處理器從特定于 I/O 包或模塊類型的閃存中加載應用程序代碼。

IS220PDIAH1A

The IS220PDIAH1A is a discrete input module manufactured by General Electric as part of the Mark VIe family for gas turbine control systems. The electrical connection between one or two I/O Ethernet networks and the discrete input terminal board is provided by the Discrete Input (PDIA) package. The component supports up to 24 contact inputs, as well as feedback signals specific to the terminal board and PDIA. The TICI type with voltage sensing isolates the connection of discrete input boards.
IS220PDIAH1A I/O packages or modules feature specific acquisition boards connected to processor boards. When the input power is applied, the soft start circuit gradually increases the available voltage on the processor board. The processor restarts and shuts down, and the local power supply turns on in sequence. After completing the self-check routine, the processor loads the application code from flash memory specific to an I/O package or module type.

IS220PDIAH1A
