MVI56-PDPS被識別為輸入/輸出模塊，并且可以訪問處理器內存以在處理器和模塊之間傳輸數據該模塊支持使用羅克韋爾自動化以太網接口通過以太網路由與ProSoft ConfigurationBuilder和FDT comDTM進行通信。此外，它還具有配置/調試串行端口，可以將PC連接到模塊以進行配置、狀態、監控和故障排除。
MVI56-PDPS模塊支持符合 IEC 61158 的完整主站規范。非循環參數數據可通過 1 或2類 DPV1 服務進行傳輸，使處理器能夠輕松與支持 PROFIBUS DPVO/V1 協議的從站設備進行通信。
MVI56-PDPS模塊充當 PROFIBUS 網絡和 ControlLogix 處理器之間的輸入/輸出模塊。來自處理器的數據傳輸與 PROFIBUS 網絡上的/0 數據傳輸異步。數據庫是用戶定義的并存儲在模塊中以保存協議所需的數據。

MVI56-PDPS

The MVI56-PDPS is recognized as an input/output module and has access to processor memory to transfer data between the processor and the module. The module supports communication with ProSoft ConfigurationBuilder and FDT comDTM via Ethernet routing using the Rockwell Automation Ethernet interface. In addition, it has a configuration/debug serial port that connects a PC to a module for configuration, status, monitoring, and troubleshooting.
The MVI56-PDPS module supports the complete master station specification according to IEC 61158. Acyclic parameter data can be transmitted via Class 1 or 2 DPV1 services, enabling the processor to easily communicate with slave devices that support the PROFIBUS DPVO/V1 protocol.
The MVI56-PDPS module acts as an input/output module between the PROFIBUS network and the ControlLogix processor. The data transfer from the processor is asynchronous with the /0 data transfer on the PROFIBUS network. The database is user-defined and stored in the module to hold the data required by the protocol.

MVI56-PDPS
